Cảm biến điện dung CE53SN08MNO Lanbao
Cảm biến điện dung CE53SN08MNO Lanbao
Click image for Gallery
Mã sản phẩm:
CE53SN08MNO
Tình trạng:
Còn hàng
Giá:
Còn hàng
Liên hệ
Trước Thuế: Liên hệ
Số lượng:
+
-
- Hoặc -
Thêm Yêu thích
Thêm so sánh
0
0 đánh giá
|
Viết đánh giá
Mô tả
Đánh giá (0)
Dimension drawing
Feature Description
Item Code
◆
Wide range of detecting object: Metal, plastic, liquid etc
◆
Reverse polarity,overloaded ,
short-circuit and surge protection
◆
Housing material :
PBT
◆
Protection degree : IP67 (IEC)
◆ High temperature up to 250℃
NPN NO
CE53SN08MNO
NPN NC
CE53SN08MNC
NPN NO+NC
——
PNP NO
CE53SN08MPO
PNP NC
CE53SN08MPC
PNP NO+NC
——
Connection diagram
Specification
Mounting
NF
SN[mm]
8mm
Housing size
55*22*96
Output
PNP NC
Power supply
18…36VDC
Frequency
60 Hz
Temperature drift
≤±10%
Hysteresis
3…20%
Repeat accuracy
≤3%
Load current
≤
250mA
Residual voltage
≤
2.5V
Consumption current
≤100mA
Protection circuit
Surge,overloaded,short-circuit,reverse polarity
Indicator
Red LED
Ambient temp.
0…60℃
Ambient RH
35-95%
Protection degree
IP54
Housing material
PA66/Teflon/Stainless steel
Connection
PVC Cable 2m
